Fiber-to-the-Home Cable Production: Manufacturing Process Explained
Did you know: more than seventy percent of U.S. broadband rollouts now use fiber networks that require high-precision manufacturing to meet performance goals.
Shanghai Weiye OFC Equipment handles complete FTTH cable production line manufacturing, from choosing brand fibers like Fujikura or Corning SMF-28e to comprehensive test documentation that ensure 100% quality assurance.
Our FTTH drop designs suit aerial, underground, and direct-buried installation, with low-smoke zero-halogen (LSZH), PVC, and polyethylene (PE) jacket options and configurations from 1 to 4 cores. We provide OS1/OS2 and multimode OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone-matched sheath colors, and logo printing.
Automated machines and high-precision equipment stabilize line speed and repeatability high. Typical lead times run four to five days for orders under 100 km and seven to ten days under 500 km, with an min. order of 1 km and warranty covering free replacement for confirmed quality issues.
Continue to learn how materials, testing, and support work together to reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment offers complete production and laboratory testing for U.S. deployments.
- A range of jacket options and fiber grades cover different install environments.
- Automated lines and machines deliver consistent quality and reliable optical performance.
- Fast lead times, low MOQ, and recognized brand fibers support reliable procurement planning.
- Complete reports and warranty support product reliability and compliance documentation needs.
Expert FTTH manufacturing by Shanghai Weiye OFC Equipment
When deadlines and performance are critical, Shanghai Weiye OFC Equipment delivers customized drop cables with complete test documentation.
As a specialized maker and supplier, Shanghai Weiye OFC Equipment pairs specialized equipment with stringent material control. We offer customized service and products for single-family and MDU rollouts. Every order comes with full QA coverage and full test reports.
Our lab conducts high heat, salt spray, and vibration testing to verify durability. Jacket options include LSZH, PVC, and PE. Designs cover bow-type flat and self-supporting styles and use brand fibers such as Fujikura® and Corning® SMF-28e.
- Documented line control and in-process checks for fully auditable shipments.
- Engineering support for specs, trials, and ramp to volume.
- Modern fixturing and calibration minimize variation so every cable matches operator specs.
FTTH cable production
At Shanghai Weiye OFC Equipment, manufacturing steps are matched to network specs, pairing brand fiber choices with disciplined test flows.
Optical fiber selection and brand options
We align fiber draw tower to minimum bend radius, attenuation, and install environment. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning SMF-28e are offered to satisfy sourcing standards.
Integrating Strength Members
Strength members employ dielectric FRP or galvanized steel wire. FRP is ideal where non-conductivity is necessary. Steel wire adds tensile strength for longer aerial spans and grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for indoor flame safety, PVC for flexibility, and PE for outdoor UV and moisture resistance. Tight process control of extruder temperature and capstan speed keeps line speed stable and dimensional tolerances.
| Component | FRP | Steel wire |
|---|---|---|
| Use case | Electrical isolation | High-tension aerial runs |
| Key benefit | Light, non-corrosive | High strength |
| Installer note | Simple terminations | Requires grounding |
Testing & Verification
Inline geometry/concentricity checks operate in-line. Final optical tests verify loss and reflectance. Each order includes a 100% test report and lab results from high heat, salt fog, and vibration trials to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Lot records and FAI approvals provide traceability and compliance for U.S. projects.
FTTH drop cable types and structures we manufacture
Shanghai Weiye OFC Equipment offers a compact portfolio of drop designs that cover tight indoor routes and exposed aerial spans. Each option pairs tested materials with geometry tuned for field termination and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It keeps bend loss low for easy routing in hallways and MDUs.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs include a support messenger to carry tensile loads. Choose dielectric FRP for electrical isolation or steel messenger when bonding and higher tensile strength are required.
Layouts & Strength Members
We provide both dielectric and metallic strength member configurations to meet safety/EMI requirements. Center loose tube and flat unitube types balance crush resistance and Fiber coloring machine for quick termination.
Indoor/outdoor jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor durability. Each series is validated for mechanical/optical performance before shipment.
| Design | Application | Strength member | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers, MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Overhead spans | FRP/Steel | Polyethylene |
| Central loose-tube | Higher fiber counts | FRP | LSZH/PE |
| Flat unitube | Low-count, easy strip | FRP/Steel | LSZH or PE |
Production line equipment that ensures quality and speed
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and boost throughput for patch cord prep.
Our production line uses automated machines that cut/strip drop cords to raise throughput and cut labor variability.
The CLX-BPO2 automated stripper uses PLC + photoelectric control. One cycle is about 1.5 seconds, giving real-world speeds near 20 terminal operations per minute.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH and PVC jackets and trims FRP or steel strength members to precise stub lengths. Cylinder-driven actuators deliver fast, repeatable motion and low downtime.
PLC & Photoelectric for Precision
PLC logic + photoelectric sensors give exact positioning and feedback control. Inline checks feed control charts so operators can adjust drifts before out-of-control conditions occur.
| Feature | Capability | Benefit |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | High throughput |
| Actuation | Pneumatic cylinders | Fast/reliable motion |
| Materials | LSZH & PVC; FRP & steel | Clean, accurate preps |
| Control | PLC/photoelectric with in-line SPC | Consistent quality, lower rework |
- Automated waste ejection and ergonomic loading keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Integrated assets and trained operators help meet FTTH volume goals without sacrificing accuracy.
CLX-BPO2 Capabilities on Our Line
The CLX-BPO2 provides industrial-grade strip/trim to our line, reducing cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC/photoelectric control enable precise detection and repeatable motion. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is 1.5s per cycle. This translates to steady throughput under normal production conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved strength member stubs are set between 7.0 and 11.0 mm to match common termination hardware.
Handling FRP and steel wire strength members
The machine cuts FRP/steel strength elements cleanly while protecting adjacent fibers. Custom tooling are available for nonstandard sizes to preserve precision.
- Auto-eject scrap and sensor-triggered start reduce idle time.
- Small footprint (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg weight ease integration into workcells.
- Pneumatic cylinders and PLC/photoelectric control improve line reliability and lower maintenance interruptions.
| Specification | Rating | Why it matters |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Compatible with common connectors |
| Reserved stub (B) | 7.0 to 11.0 mm | Supports termination strength |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 supports our lines in meeting volume targets without compromising quality.
Custom Specs for Your FTTH System
Shanghai Weiye OFC Equipment configures every order to meet your network requirements and simplify field rollout. We combine focused options with predictable schedules so your teams get install-ready reels.
Choose 1 to 4 cores with SM or MM fiber. Options include OS1, OS2, and OM2–OM4 along with G.652D/G.657 variants to match your optics and connector plans.
We Pantone-match sheath colors for fast field ID and consistent asset tags.
Branding and Print Options
Select LSZH/PVC/PE jackets based on route and safety rules. Custom print legends and logos support inventory and warranty tracking.
Length options, packaging, and special structures
Standard put-ups are 1/2/4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.
| Option | Common choice | Advantage |
|---|---|---|
| Reel length | 1, 2, or 4 km | Simpler staging and reels |
| Sheath | LSZH, PE, PVC | Indoor/outdoor compatibility |
| Structure | Bow-type / Self-supporting | Routing and span flexibility |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and provides docs that detail final specs for straightforward QA on site.
Quality assurance, testing, and documentation
Shanghai Weiye OFC Equipment embeds quality checkpoints across the production line so every item ships with recorded acceptance data.
High-temperature, salt spray, and vibration laboratory testing
Our lab runs elevated-temperature exposure, salt spray corrosion, and vibration tests to qualify materials/assemblies. These tests recreate field stresses for indoor and outdoor use.
Full Test Reports for Every Reel
Every fiber optic cable ships with a 100% test report that records loss, return loss, and key geometry where applicable. Final QC gates prevent nonconforming shipments before they leave the factory.
Audit Trail and Compliance
Batch records link tests to reels/serials so audits and warranty claims are simple to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection prevent field failures and cut warranty events.
- QA packages include spec confirmation and formatted data for rapid review.
- Ongoing trend analysis inform preventive maintenance and raise long-term reliability.
| Trial | Purpose | Outcome |
|---|---|---|
| Heat exposure | Material stability | Pass at target temperature |
| Salt-fog | Corrosion robustness | Outdoor suitability |
| Vibration | Mechanical robustness | Reduced field failures |
FTTH Drop Cable Pricing & Cost Drivers
Budgeting for a drop run begins with fiber/jacket selection and is shaped by volume and customization.
Typical prices vary widely—from about $30 to $1,000 per unit—based on fiber grade, jacket chemistry (LSZH, PVC, PE), length, and design structure.
Materials, Grade, Jacket & Structure
The primary cost drivers are fiber grade, jacket material, and the structural type chosen for deployment.
Self-supporting structures and steel members raise material and labor input. Custom sheath colors/logos/legends add setup and influence price for short runs.
Length/Volume/Customization Impact
Longer put-ups and larger volumes lower unit cost. Short runs often include setup charges and higher unit prices.
- Changeovers and special cutters extend lead time and add cost.
- Clear RFQs and line scheduling let Shanghai Weiye OFC Equipment match quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets across phases.
| Factor | Effect on price | Guidance |
|---|---|---|
| Fiber grade | High impact | Right-size spec to budget |
| Sheath material | Medium impact | Compare LSZH vs. PE for total cost |
| Length/Volume | Large | Consolidate where possible |
U.S. Lead Times, MOQ & Delivery
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align crews and sites. Predictable windows cut downtime and control costs when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for orders under 500 km. We plan capacity to track your milestones and to keep deliveries on time.
The service team provides updates/tracking so installation teams can plan arrivals. For compressed schedules, we hold contingency capacity to accelerate critical-path orders.
Minimum order quantity and why it matters
The MOQ is 1 km. This reflects setup needs such as wire and jacket die adjustments that use startup material and generate scrap.
We review your put-ups and staging to choose reel sizes that cut waste and handling. Staggered batches can balance inventory holding with more frequent small-site deliveries.
Installation readiness and application scenarios
On-site conditions dictate whether a self-supporting aerial, duct pull, or direct burial is the right choice for a project.
Aerial vs Duct vs Direct-Buried
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to manage sag/tension for long-term reliability.
Duct installations perform best with low-friction sheaths and crush-resistant builds so pulling avoids fiber damage. PE jackets are common for underground and buried paths where moisture resistance matters.
Direct-buried designs need correct burial depth per local codes and moisture-resistant jackets to protect the optic core over time.
Indoor riser/plenum distribution and ONT termination
Indoor riser and plenum routes prefer LSZH to meet smoke/flame codes. Flat drop profiles strip clean and present controlled stubs for fast ONT terminations.
We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning risk, and hardware fit. Standardized line prep shortens install time and reduces scrap.
| Scenario | Key feature | Field note |
|---|---|---|
| Aerial | Self-supporting (steel/FRP) | Verify messenger hardware/tension |
| Underground duct | Low-friction, crush-resistant | Use pull tape + lubricant |
| Direct-buried | PE with moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at penetrations |
Our approach delivers a consistent installation across indoor/outdoor transitions. That leads to fewer callbacks, faster activations, and stable field performance for your system.
End-to-end support and after-sales service
Our team coordinates tests, line schedules, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements capture through approved drawings and pilot builds. We provide doc templates and clear installation notes so field crews work from the same plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full reports and traceability to support QA acceptance.
- Round-the-clock availability for status and technical support.
- Warranty includes free replacement for confirmed quality issues.
- Schedule coordination for expedites and urgent changes.
- Configuration control so shipped items match agreed requirements every time.
| Support area | Scope | Outcome |
|---|---|---|
| Tech/Eng | Spec review & pre-production builds | Fewer field issues |
| Testing | Lab trials & 100% test reports | Traceable quality |
| Service | Rapid replacement & root-cause | Minimized downtime |
Conclusion
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that pair material choices with validated manufacturing and lab testing. Every reel includes a 100% test report and documented trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2 prep assets, cuts variability and shortens turnaround. Our equipment set standardize strip and stub lengths so installers see consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated customer support guides scheduling, logistics, and after-sales care so your deployment stays on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every shipment with laboratory validation and responsive service.
